21 support@yardistrystructures.com
#10x 4” Wood Screws
Connects Right and Left Posts to FB Wall
Panels
F: Attach (1108) Left Post and (1109) Right Post to top and bottom of (1147) FB Panel with two #10 x 4” Wood
Screws per post. (F2.9)
F2.9
Hardware
4 x #10 x 4” Wood Screw
(1147)
FB Panel
(1108) Left
Post
(1109) Right
Post
(1147)
FB Panel
#10 x 4”
Wood
Screw
#10 x 4”
Wood
Screw
Step 2: Front Wall Assembly
Part 4
