YASKAWA 1000 Series

9 Input Assemblies (Drive Produces)
56 YASKAWA ELECTRIC SIEP C730600 43B 1000-Series Option SI-N3 Technical Manual
 Standard DI/DO Status (Vendor Specific Yaskawa Electric (YE) Assy) - 157 (0x9D)
Input
Instance
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
157
0 FAULT ALARM READY
Speed
Agree
Reset
REV
Running
ZSP Running
1–––––
LOCAL/
REMOTE
Uv oPE
2
Multi-
Function
Input 8
Multi-
Function
Input 7
Multi-
Function
Input 6
Multi-
Function
Input 5
Multi-
Function
Input 4
Multi-
Function
Input 3
Multi-
Function
Input 2
Multi-
Function
Input 1
3– –
Multi-
Function
Photocoupler
2
Multi-
Function
Photocoupler
1
Multi-
Function
Digital
Output
–––
4 Analog Input 1 (Low Byte)
5 Analog Input 1 (High Byte)
6 Output Frequency (Low Byte)
7 Output Frequency (High Byte)
Parameter Data
Running
Running
0: Stop
1: Forward or Reverse Running
ZSP
Zero Speed
0: Running
1: Stop or DC Injection Braking
REV Running
Reverse Running
0: Not Reverse Running
1: Reverse Running
Reset
Reset
0: No Reset
1: Reset
Speed Agree
Speed Agree
0: No Speed Agree
1: Actual speed at speed reference
READY
Drive Ready
0: Not Ready
1: Ready
ALARM
Drive Alarm
0: No Drive Alarm
1: Alarm
FAULT
Drive Fault
0: No Drive Fault
1: Fault
oPE
oPE Fault
0: No oPExx Fault
1: oPExx
Uv
Undervoltage
0: No Undervoltage
1: Undervoltage
LOCAL/REMOTE
Status of Run command from Network
0: Run command is not from network
1: Run command is from network
Multi-Function Input 1
Terminal S1
0: Terminal S1 OFF
1: Terminal S1 ON
Multi-Function Input 2
Terminal S2
0: Terminal S2 OFF
1: Terminal S2 ON
