10 General Class Objects
YASKAWA ELECTRIC SIEP C730600 43B 1000-Series Option SI-N3 Technical Manual 61
10 General Class Objects
Identity Object - 1 (Class 0x01)
Services Supported
Attributes Supported
Message Router Object - 2 (Class 0x02)
Services Supported
Attributes Supported
DeviceNet Object - 3 (Class 0x03)
Services Supported
Service Code No. (hex) Service Name
0E Get Attribute Single
10 Set Attribute Single
05 Reset
Instance
ID
Attribute Name Description Get Set Size Range Default
01
Object Software
Revision
The Identity Object software revision { Word 1
1 1 Vendor ID
Manufacturer code.
44 (2C Hex): Yaskawa Electric
{ Word 44 (YASKAWA)
1 2 Device Type
The device profile.
The profile for this product is an AC
drive.
2: AC drive
{ Word 2 (AC Drives)
1 3 Product Code
Product codes determined by the
manufacturer.
{ –Word
<1>
<1> Product code is 2 bytes. The first byte is the drive type and the second byte is the model number of the drive.
1 4 Revision Software revision for the option card. { Word Depends on software
1 5 Status The comm. status for the drive. { Word 0
1 6 Serial Number Option card serial number { Long Each unit is unique
1 7 Product Name Product name. {
String
(14
Bytes)
Product-dependent
ex: CIMR-AA2A0004
18State
The operation status of the drive.
3: Drive ready
4: Fault
{ –Byte 3
19
Configuration
Consistency Value
Shows verification data for any
parameters that have been edited from
their default values.
{ Word 0000
1 10 Heartbeat Interval Heartbeat interval. {{ Word 0 to 10 0=disabled
Service Code No. (hex) Service Name
0E Get Attribute Single
Instance
ID
Attribute Name Description Get Set Size Default
0 1 Object Software Revision The Message Router object software revision { –Word 1
Service Code No. (hex) Service Name
0E Get Attribute Single
