YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
25/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N•m㻌
Size㻌 Shape㻌
A1000 CIMR-AA4A0250
R/L1,S/L2,T/L3 38 - 325㻌
M10㻌
Hexagon bolt
(with Phillips
screwhead)㻌
18 - 23㻌
U/T1,V/T2,W/T3㻌 38 - 325㻌
-,+1㻌 80 - 325㻌
+3㻌 38 - 325㻌
肀㻌
22 - 200㻌 Minus (-)㻌
CR700 CR70A4216
R/L1,S/L2,T/L3 22 - 100x2P㻌
M10㻌
Hexagon bolt
and Nut㻌
20㻌
U/T1,V/T2,W/T3㻌 22 - 100x2P㻌
-,+1㻌 30 - 125x2P㻌
+3㻌 22 - 60x2P㻌
肀㻌
22 - 200㻌 M10㻌
Hexagon bolt
with slot㻌
18 - 23㻌
A1000 CIMR-AA4A0296
R/L1,S/L2,T/L3 80 - 325㻌
M12㻌
Hexagon bolt
(with Phillips
screwhead)㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 80 - 325㻌
-,+1㻌 80 - 325㻌
+3㻌 38 - 325㻌 M10㻌 18 - 23㻌
肀㻌
30 - 200㻌 M12㻌 Minus (-)㻌 32 - 40㻌
CR700 CR70A4260
R/L1,S/L2,T/L3 22 - 100x2P㻌
M10㻌
Hexagon bolt
and Nut㻌
20㻌
U/T1,V/T2,W/T3㻌 22 - 100x2P㻌
-,+1㻌 30 - 125x2P㻌
+3㻌 22 - 60x2P㻌
肀㻌
30 - 200㻌 M10㻌
Hexagon bolt
with slot㻌
18 - 23㻌
A1000 CIMR-AA4A0362
R/L1,S/L2,T/L3 80 - 325㻌
M12㻌
Hexagon bolt
(with Phillips
screwhead)㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 80 - 325㻌
-,+1㻌 100 - 325㻌
+3㻌 80 - 325㻌 M10㻌 18 - 23㻌
肀㻌
30 - 200㻌 M12㻌 Minus (-)㻌 32 - 40㻌
CR700 CR70A4304
R/L1,S/L2,T/L3 60 - 125x2P㻌
M12㻌
Hexagon bolt
and Nut㻌
35㻌
U/T1,V/T2,W/T3㻌 60 - 125x2P㻌
-,+1㻌 100 - 150x2P㻌
+3㻌 38 - 150x2P㻌
肀㻌
30 - 200㻌 M12㻌
Hexagon bolt
with slot㻌
32 - 40㻌
A1000 CIMR-AA4A0414
R/L1,S/L2,T/L3 80 - 150㻌
M12㻌
Hexagon bolt
and Nut㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 80 - 150㻌
-,+1㻌 80 - 150㻌
+3㻌 80 - 150㻌
肀㻌
38 - 100㻌 Minus (-)㻌
CR700 CR70A4371
R/L1,S/L2,T/L3 60 - 125x2P㻌
M12㻌
Hexagon bolt
and Nut㻌
35㻌
U/T1,V/T2,W/T3㻌 60 - 125x2P㻌
-,+1㻌 100 - 150x2P㻌
+3㻌 38 - 150x2P㻌
肀㻌
38 - 200㻌 M12㻌
Hexagon bolt
with slot㻌
32 - 40㻌

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
