YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
26/44
Model
Drive Capacity
A1000: Model
CR700: Catalog
code
Terminal Symbol
Applicable
Gauge
mm
2
Terminal Screw㻌
Tightening
Torque
N•m㻌
Size㻌 Shape㻌
A1000 CIMR-AA4A0515㻌
R/L1,S/L2,T/L3 80 - 150㻌
M12㻌
Hexagon bolt
and Nut㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 80 - 150㻌
-,+1㻌 60 - 150㻌
+3㻌 60 - 150㻌
肀㻌
50 - 150㻌 Minus (-)㻌
CR700 CR70A4453㻌
R/L1,S/L2,T/L3㻌
R1/L11,S1/L21,T1/L31㻌
60 - 125x4P㻌
M12㻌
Hexagon bolt
and Nut㻌
35㻌
U/T1,V/T2,W/T3㻌 60 - 150x4P㻌
-,+1㻌 80 - 150x4P㻌
+3㻌 30 - 125x4P㻌
肀㻌
60 - 150㻌 M12㻌
Hexagon bolt
with slot㻌
32 - 40㻌
A1000 CIMR-AA4A0675㻌
R/L1,S/L2,T/L3 80 - 150㻌
M12㻌
Hexagon bolt
and Nut㻌
32 - 40㻌
U/T1,V/T2,W/T3㻌 80 - 150㻌
-,+1㻌 60 - 150㻌
+3㻌 60 - 150㻌
肀㻌
70 - 150㻌 Minus (-)㻌
CR700 CR70A4605㻌
R/L1,S/L2,T/L3㻌
R1/L11,S1/L21,T1/L31㻌
60 - 125x4P㻌
M12㻌
Hexagon bolt
and Nut㻌
35㻌
U/T1,V/T2,W/T3㻌 60 - 150x4P㻌
-,+1㻌 80 - 150x4P㻌
+3㻌 30 - 125x4P㻌
肀㻌
60 - 150㻌 M12㻌
Hexagon bolt
with slot㻌
32 - 40㻌

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
