7.1 Cable Configurations
7-2
7.1
Cable Configurations
The Servomotor Main Circuit Cables and Encoder Cables are installed away from the load.
You cannot install these Cables toward the load.
No. Cable Type Reference
Servomotor Main Circuit Cables for Servomotors without Holding Brakes
page 7-3
Servomotor Main Circuit Cables for Servomotors with Holding Brakes
page 7-4
Encoder Cables of 20 m or less for Incremental Encoders
page 7-5
Encoder Cables of 20 m or less with Battery Cases for Absolute Encoders
page 7-6
Relay Encoder Cables of 30 m to 50 m
page 7-7
Relay Encoder Cables with a Battery Case
User-Assembled Wiring Materials for Encoder Cables
Connector Kits
page 7-9
Cables without Connectors
page 7-10
Important
Servomotor Main Circuit Cables

Encoder Cables
