YASKAWA E Series User Manual

8.2 Servomotor Main Circuit Cables
8.2.3 Main Circuit Cables for SGM7F-M, -N, and SGMCS Motors
8-10
Note: 1. Refer to the following section for information on connector specifications, manufacturers, and order num-
bers.
SGM7E Servomotors, SGM7F-
 A to -  D Servomotors, SGMCV Servomotors, and SGMCS Small-
Capacity, Coreless Servomotor on page 8-13
SGM7F-
 M or -  N Servomotors and SGMCS Medium-Capacity Servomotors with Cores on page 8-
14
2. Refer to the following section for information on wiring material specifications and order numbers.
Main Circuit Cables for SGM7E Servomotors and SGMCS Small-Capacity, Coreless Servomotors on page
8-17
Yaskawa does not specify what wiring materials to use for SGM7F-M and -N Servomotors and
SGMCS Medium-Capacity Servomotors with Cores. Use appropriate wiring materials for the current spec-
ifications and connectors.
Wiring Specifications
 JZSP-CM--E (Standard/Flexible Cables)
 JZSP-USA10
 -  -E, JZSP-USA30  -  -E, and JZSP-USA50  -  -E
(Standard Cables)
 JZSP-USA12
 -  -E, JZSP-USA32  -  -E, and JZSP-USA52  -  -E
(Flexible Cables)
Pin
Signal
Signal
Wire Color
1
2
3
4
Motor end
FG
Phase W
Phase V
Phase U
FG
Phase W
Phase V
Phase U
Green/(yellow)
Blue
White
Red
SERVOPACK end
Pin
Signal
Signal
Wire Color
A
B
C
D
Motor end
FG
Phase W
Phase V
Phase U
FG
Phase W
Phase V
Phase U
Green
Black
White
Red
SERVOPACK end
Pin
Signal
Signal
Wire Color
A
B
C
D
Motor end
FG
Phase W
Phase V
Phase U
FG
Phase W
Phase V
Phase U
Green/yellow
Blue
White
Red
SERVOPACK end
