YASKAWA E Series User Manual

8.3 User-Assembled Wiring Materials for Servomotor Main Circuit Cables
8.3.1 Servomotor Connector Kits
8-14
SGM7F-M or -N Servomotors and SGMCS Medium-
Capacity Servomotors with Cores
 Connector Configurations
Note: 1. Servomotor Connectors (receptacles) are compatible with MS Connectors. If you prepare your own cables,
refer to the connector number in parentheses for the model number of the MS connector and select the
appropriate plug.
2. Yaskawa does not specify what wiring materials to use. Use appropriate wiring materials for the current
specifications and connectors.
 External Dimensions
 Straight Plugs: N/MS3106B18-10S
Unit: mm
Servomotor Model
Servomotor Connector
Model (Receptacle)
Order Number
Manufac-
turer
Straight Plug
Right-Angle Plug
Cable Clamp
Japan
Aviation
Electron-
ics Indus-
try, Ltd.
SGMCS-M
SGMCS-
N
CE05-2A18-10PD-D
(MS Connector model:
MS3102A18-10P)
N/MS3106B18
-10S
N/MS3108B18
-10S
N/MS3057
-10A
Part
Shell
Size
Joint Thread
A
Length of
Joint
J ±0.12
Tot al
Length
L Max.
Joint Nut
Outer
Diameter
QDia.
Cable
Clamp
Mounting
Thread
V
Effec-
tive
Thread
Length
W Min.
Maxi-
mum
Width
Y Max.
N/MS3106B18-10S 18
1-1/8-
18UNEF
18.26 52.37 34.13 1-20UNEF 9.53 42
Cable Clamp Cable
Straight Plug
Right-Angle Plug
Servomotor Connector
(receptacle)
A
B
C
D
J
W
A
V
Y
Q
L
+0
-0.38
