YASKAWA E Series User Manual

8.3 User-Assembled Wiring Materials for Servomotor Main Circuit Cables
8.3.1 Servomotor Connector Kits
8
Cables and User-Assembled Wiring Materials for Direct Drive Servomotors
8-15
 Right-Angle Plug: N/MS3108B18-10S
Unit: mm
 Cable Clamp: N/MS3057-10A
Unit: mm
Note: A rubber bushing is included.
Part
Shell
Size
Joint Thread
A
Length
of Joint
J ±0.12
Tota l
Length
L Max.
Joint Nut
Outer
Diameter
QDia.
R
± 0.5
U
± 0.5
Cable
Clamp
Mounting
Thread
V
Effec-
tive
Thread
Length
W Min.
N/MS3108B18-
10S
18
1-1/8-
18UNEF
18.26 68.27 34.13 20.5 30.2 1-20UNEF 9.53
Part
Appli-
cable
Con-
nector
Shell
Size
Tot al
Length
A ±0.7
Effec-
tive
Thread
Length
C
E
Dia.
G ±0.7 H
J
Dia.
Mounting
Thread
V
Outer
Diame-
ter
Q ±0.7
Dia.
Attached
Bushing
N/MS3057-
10A
18 23.8 10.3 15.9 31.7 3.2 14.3 1-20UNEF 30.1 AN3420-10
U
R
W
J
A
Q
L
V
+0
-0.38
G
H (slide range)
E dia.
(Cable Clamp
inner diameter)
J dia. (inner diameter of bushing)
A
V
Q dia.
1.6
C
