YASKAWA E Series User Manual

9.3 Cable Selection Table
9.3.6 Cable Dimensional Drawings and Wiring Specifications
9
Cables and User-Assembled Wiring Materials for Linear Servomotors
9-27
JZSP-CLL10--E Sensor Cables
• Wiring Specifications
JZSP-CL2L100--E Sensor Cables
• Wiring Specifications
1
5
6
9
1
5
6
9
L
Connector: 17JE-23090-02(D8C) -CG
(9-pin, soldered)
DDK Ltd.
Cable (UL20276)
(AWG22 × 2C + AWG24 × 2P)
Connector: 17JE-13090-02(D8C)A-CG
(with stud) (9-pin, soldered)
DDK Ltd.
Polarity sensor end
Finished diameter: 6.8 mm
Serial Converter Unit end
1
2
3
4
5
7
8
9
6
+5 V
0 V
–
–
–
–
–
–
–
–
+5 V
0 V
1
2
3
4
5
7
8
9
6
Serial Converter Unit end
Pin Pin SignalSignal
Case
Shield
Phase-W input
Phase-V input
Phase-U input
Phase-V input
Phase-U input
Phase-W input
Shield
Case
Polarity sensor end
1
5
6
9
1
5
6
9
L
(AWG22 × 2C + AWG24 × 2P)
Connector: 17JE-13090-02(D8C)A-CG
(with stud) (9-pin, soldered)
DDK Ltd.
Cable (UL20276)
Connector: 17JE-23090-02(D8C)-CG
(9-pin, soldered)
DDK Ltd.
Polarity sensor end
Finished diameter: 6.8 mm
Serial Converter Unit end
1
2
3
4
5
7
8
9
6
+5 V, Thermal
Protector
0 V
–
–
–
–
–
–
0 V
1
2
3
4
5
7
8
9
6
+5 V, Thermal
Protector
Serial Converter Unit end
Pin Pin SignalSignal
Case
Shield
Thermal Protector
Phase-W input
Phase-V input
Phase-U input
Phase-V input
Phase-U input
Phase-W input
Shield
Case
Polarity sensor end
Thermal Protector
