YASKAWA E Series User Manual

12.8 Regenerative Resistor
12.8.3 Selection Table
12
SERVOPACK Peripheral Devices
12-33
12.8.3 Selection Table
*1. Refer to the following section for the specifications of built-in regenerative resistors.
12.8.4 Specifications of Built-in Regenerative Resistors in SERVOPACKs on page 12-33
*2. Regenerative Resistor Units are available. Refer to the following section for details.
Regenerative Resistor Units on page 12-36
12.8.4 Specifications of Built-in Regenerative Resistors in
SERVOPACKs
The following table gives the specifications of the built-in regenerative resistors in the SERVO-
PACKs and the amount of regenerative power (average values) that they can process.
*1. Values in parentheses are for the optional JUSP-RA04-E Regenerative Resistor Unit.
*2. Values in parentheses are for the optional JUSP-RA05-E Regenerative Resistor Unit.
SERVOPACK Model Built-In
Regener-
ative
Resistor
External
Regenerative
Resistor
Description
SGD7S-
SGD7W-
SGD7C-
R70A, R90A,
1R6A, 2R8A,
R70F, R90F,
2R1F, or 2R8F
−
Not pro-
vided.
Basically not
required.
There is no built-in regenerative resistor, but
normally an External Regenerative Resistor is
not required.
Install an External Regenerative Resistor when
the smoothing capacitor in the SERVOPACK
cannot consume all the regenerative power.
3R8A, 5R5A,
7R6A,
120A,180A,
200A, or
330A
1R6A, 2R8A,
5R5A, or
7R6A
Standard
feature
*1
Basically not
required.
A built-in regenerative resistor is provided as a
standard feature. Install an External Regenera-
tive Resistor when the built-in regenerative
resistor cannot process all of the regenerative
power.
470A, 550A,
590A, or
780A
−
Not pro-
vided.
Required.
*2
A built-in regenerative resistor is not provided.
An External Regenerative Resistor is required.
If the External Regenerative Resistor is not
connected to the SERVOPACK, a Regenera-
tion Alarm (A.300) will occur.
SERVOPACK Model
Built-In Regenera-
tive Resistor
Regenerative
Power Processing
Capacity of Built-
in Regenerative
Resistor
[W]
Minimum
Allowable
Resistance
[Ω]
SGD7S-
SGD7W-
SGD7C-
Resis-
tance
[Ω]
Capac-
ity
[W]
R70A, R90A, 1R6A, 2R8A,
R70F, R90F, 2R1F, or 2R8F
−−−−40
3R8A, 5R5A, or 7R6A 1R6A or 2R8A 40 40 8 40
120A − 20 60 12 20
120A008, 180A, or
200A
5R5A or 7R6A 12 60 12 12
330A − 8 180 36 8
470A −
(6.25)
*1
(880)
*1
(180)
*1
5.8
550A, 590A, or 780A −
(3.13)
*2
(1760)
*2
(350)
*2
2.9
