12.8 Regenerative Resistor
12.8.6 Selecting External Regenerative Resistor
12-38
 SERVOPACK Model: SGD7S-3R8A, -5R5A, -7R6A, -120A, -180A,
-200A,-330A, -470A, -550A, -590A, or
-780A
SGD7W-1R6A, -2R8A, -5R5A, or -7R6A
SGD7C-1R6A, -2R8A, -5R5A, or -7R6A
The above SERVOPACKs require regenerative resistors. Regenerative resistors are built into all
of the SERVOPACKs in advance except for the SGD7S-470A, -550A, -590A, and -780A. If you
use the SGD7S-470A, -550A, -590A, or -780A, always provide an external regenerative resis-
tor. Refer to the following section for details.
12.8.3 Selection Table on page 12-33
The allowable frequencies for regenerative operation of the Servomotor without a load in accel-
eration/deceleration operation during an operation cycle from 0 (min
-1
) to the maximum motor
speed and back to 0, are listed below. For the SGD7S-470A, -550A, -590A, and -780A, the
allowable frequencies are given for when a Regenerative Resistor Unit is connected. Refer to
the following section for details on Regenerative Resistor Units.
Regenerative Resistor Units on page 12-36
Convert the data into the values for the actual motor speed and load moment of inertia to
determine whether an External Regenerative Resistor is required.

Rotary Servomotors
Servomotor Model
Allowable Frequencies in
Regenerative Operation
(Rotations/Min)
Servomotor Model
Allowable Frequencies in
Regenerative Operation
(Rotations/Min)
SERVOPACK
Model:
SGD7S
SERVOPACK
Model:
SGD7W or
SGD7C
(Simultane-
ous Opera-
tion of Two
Axes)
SERVOPACK
Model:
SGD7S
SERVOPACK
Model:
SGD7W or
SGD7C
(Simultane-
ous Opera-
tion of Two
Axes)
SGM7M-
A1A −−
SGM7P-
01A − 200
A2A −− 02A − 46
A3A −− 04A − 29
SGM7J-
A5A − 300 08A 11 11
01A − 180 15A 7.5 −
C2A − 130
SGM7G-
03A 39 39
02A − 46 05A 29 29
04A − 25 09A 6.9 6.9
06A 30 30 13A 6.1 −
08A 15 15 20A 7.4 −
SGM7A-
A5A − 560 30A 9.5 −
01A − 360 44A 6.4 −
C2A − 260 55A 24 −
02A − 87 75A 34 −
04A − 56 1AA 39 −
06A 77 77 1EA 31 −
08A 31 31
SGMMV-
A1A −−
10A 31 − A2A −−
15A 15 − A3A −−
20A 19 −
25A 15 −
30A 6.9 −
40A 11 −
50A 8.8 −
70A 86 −
