YASKAWA F7 Programming Manual

Programming 137
 o1 Monitor Configuration
 o1-01 User Monitor Selection
Setting Range: 4 to 45
Factory Default: 6
Setting Description
4 Control Method
5 Motor Speed
6 Output Voltage (factory default)
7 DC Bus Voltage
8 Output Power
9 Torque Reference
10 Input Terminal Status
11 Output Terminal Status
12 Drive Operation Status
13 Cumulative Operation Time
14 Software Number
15 Terminal A1 Level
16 Terminal A2 Level
17 Terminal A3 Level
18 Motor Secondary Current (I
q
)
19 Motor Excitation Current (I
d
)
20 Output Frequency After Soft Start
21 ASR Input
22 ASR Output
24 PID Feedback Value
25 DI-16H2 Input Status
26 Output Voltage Reference (V
q
)
27 Output Voltage Reference (V
d
)
28 CPU Number
29 Kilowatt-Hours Low 4 Digits
30 Kilowatt-Hours High 5 Digits
32 ACR Output of q Axis
33 ACR Output of q Axis
34 First Parameter Causing an OPE
35 Zero Servo Pulse Count
36 PID Input
37 PID Output
38 PID Setpoint
39 Memobus Communication Error Code
40 Heatsink Cooling Fan Operation Time
44 ASR Output Without Filter
45 Feed Forward Control Output
