Programming 50
E1 V/f Pattern
E1-01 Input Voltage Setting
Setting Range: 155.0V to 255.0V (240V Models)
310.0V to 510.0V (480V Models)
Factory Defaults: 240.0V (240V Models)
480.0V (480V Models)
Set the Input Voltage parameter (E1-01) to the nominal voltage of the connected AC power supply. This parameter adjusts the
levels of some protective features of the Drive (i.e. Overvoltage, Stall Prevention, etc.). E1-01 also serves as the Maximum/Base
Voltage used by the Preset V/Hz curves (E1-03= 0 to E).
E1-03 V/f Pattern Selection
The Drive operates utilizing a set V/f pattern to determine the appropriate output voltage level for each commanded speed. There
are 15 different preset V/f patterns to select from with varying voltage profiles, saturation levels (frequency at which maximum
voltage is reached), and maximum frequencies.
There are also settings for Custom V/f patterns that will allow the programmer to manually set (“Customize”) the V/f pattern
using parameters E1-04 through E1-13.
Using parameter E1-03, the programmer can select one of the preset V/f patterns or chose between a custom V/f pattern with an
upper voltage limit (E1-03= “F: Custom V/F”) and a custom V/f pattern without a voltage limit (E1-03= “FF: Custom w/o limit”).
WARNING
DRIVE INPUT VOLTAGE (NOT MOTOR VOLTAGE) MUST BE SET IN E1-01 FOR THE PROTECTIVE
FEATURES OF THE DRIVE TO FUNCTION PROPERLY. FAILURE TO DO SO MAY RESULT IN
EQUIPMENT DAMAGE AND/OR PERSONAL INJURY.
Setting Description
0 50 Hz
1 60 Hz Saturation
2 50 Hz Saturation
3 72 Hz
4 50 Hz VT1
5 50 Hz VT2
6 60 Hz VT1
7 60 Hz VT2
8 50 Hz HST1
9 50 Hz HST2
A 60 Hz HST1
B 60 Hz HST2
C 90 Hz
D 120 Hz
E 180 Hz (not supported at this time)
F Custom V/f (factory default, with parameter values per setting 1)
FF Custom w/o limit
