Programming 188
COPY Function
o3-01
Copy Function Selection
Copy Function Sel
This parameter controls the copying of parameters to and from the
Digital Operator.
0: COPY SELECT (no function)
1: INV -> OP READ - All parameters are copied from the
Drive to the Digital Operator.
2: OP -> INV WRITE - All parameters are copied from the
Digital Operator to the Drive.
3: OP<-->INV VERIFY - Parameter settings in the Drive are
compared to those in the Digital
Operator.
NOTE: When using the copy function, the Drive model number
(o2-04), software number (U1-14), and control method
(A1-02) must match or an error will occur.
0 to 30AAA A
o3-02
Copy Allowed Selection
Read Allowable
Enables and disables the Digital Operator copy functions.
0: Disabled - No Digital Operator copy functions are allowed.
1: Enabled - Copying allowed.
0 to 10AAA A
Auto-Tuning
T1-00
Motor Selection 1 / 2
Select Motor
Selects which set of motor parameters are to be used and set during
Auto-Tuning. If Motor 2 selection (H1-XX=16) is not selected, this
parameter will not be displayed.
1: 1st Motor - E1 to E2
2: 2nd Motor - E3 to E4
1, 2 1 A A A A
T1-01
Auto-Tuning mode selection
Tuning Mode Sel
Selects the Auto-Tuning mode.
0: Rotational Auto-Tuning (A1-02 = 2 or 3)
1: Stationary Auto-Tuning (A1-02 = 2 or 3)
2: Terminal resistance only, (stationary) Auto-Tuning (A1-
02 = 0, 1, 2, or 3)
0 to 20AAA A
T1-02
Motor Rated Power
Mtr Rated Power
Set the motor rated power in kilowatts (kW).
NOTE:If motor power is given in horsepower, power in kW can be
calculated using the following formula: kW = Hp * 0.746
0.00 to
650.00
kW
Va ri es
by
kVA
AA A A
T1-03
Motor rated voltage
Rated Voltage
Set the motor rated voltage in Volts (V).
0.0 to
255.0
(240V)
0.0 to
510.0
(480V)
230Vac
or
460Vac
-- A A
T1-04
Motor Rated Current
Rated Current
Set the motor rated current in Amperes (A).
Va ri es
by
kVA
Va ri es
by
kVA
AA A A
T1-05
Motor Base Frequency
Rated Frequency
Set the base frequency of the motor in Hertz (Hz).
Va ri es
by
Duty
Rating*
60.0Hz - - A A
T1-06
Number of Motor Poles
Number of Poles
Set the number of motor poles. 2 to 48 4 poles - - A A
T1-07
Motor Base Speed
Rated Speed
Set the base speed of the motor in revolutions per minute (RPM).
0 to
24000
1750
RPM
-- A A
T1-08
Number of PG Pulses
PG Pulses / Rev
Set the number of pulses per revolution (PPR) for the encoder
(pulse generator) being used without any multiplication factor.
0 to
60000
1024
PPR
-- - A
Denotes that parameter can be changed when the Drive is running.
* For Heavy Duty (HD) Rating: Setting Range=0.0 to 300.0. For Normal Duty (ND) Rating: Setting Range=0.0 to 400.0.
Table A.1 F7 Parameter List (Continued)
Parameter
No.
Parameter Name
Digital Operator Display
Description
Setting
Range
Factory
Setting
Control Method
V/F
V/F
w/
PG
Open
Loop
Vector
Flux
Vector
To Next Page
