YASKAWA F7 Programming Manual

Programming 54
Table 9 V/f Pattern Default Settings for Drive Capacity 0.4~1.5kW for 240V Class (Continued)
Parameter
No.
Name Unit Factory Setting
E1-03 V/f Pattern Selection — 8 9 A B C D E F
E1-04 Max. Output Frequency Hz 50.0 50.0 60.0 60.0 90.0 120.0 180.0 60.0
E1-05 Max. Output Voltage V 240.0 240.0 240.0 240.0 240.0 240.0 240.0 240.0
E1-06 Base Frequency Hz 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Mid. Output Frequency A V 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0
E1-08 Mid. Output Voltage A V 21.8 27.6 21.8 27.6 17.2 17.2 17.2 17.2
E1-09 Min. Output Frequency Hz 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5
E1-10 Mid. Output Voltage V 12.6 14.9 12.6 17.2 10.3 10.3 10.3 10.3
E1-11Mid Output Frequency BHz 0 0 0 00000
E1-12Mid Output Voltage B V 0 0 0 00000
E1-13Base Voltage V 0 0 0 00000
For 480V class units, the value is twice that of 240V class units.
Table 10 V/f Pattern Default Settings for Drive Capacity 2.2~45kW for 240V Class
Parameter
No.
Name Unit Factory Setting
E1-03 V/f Pattern Selection — 0 1 2 3 4 5 6 7
E1-04 Max. Output Frequency Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0
E1-05 Max. Output Voltage V 240.0 240.0 240.0 240.0 240.0 240.0 240.0 240.0
E1-06 Base Frequency Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0
E1-07 Mid. Output Frequency A V 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0
E1-08 Mid. Output Voltage A V 16.1 16.1 16.1 16.1 40.2 57.5 40.2 57.5
E1-09 Min. Output Frequency Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5
E1-10 Mid. Output Voltage V 8.0 8.0 8.0 8.0 6.9 8.0 6.9 8.0
E1-11 Mid Output Frequency B Hz 0 0 0 0 0 0 0 0
E1-12Mid Output Voltage B V 0 0 0 00000
E1-13 Base Voltage V 0 0 0 0 0 0 0 0
For 480V class units, the value is twice that of 240V class units.

YASKAWA F7 Specifications

General

Series	F7
Type	DC Drive
Feedback	Tachometer, Encoder
Communication	RS-485, DeviceNet, Profibus, Modbus
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Storage Temperature	-20°C to +70°C (-4°F to 158°F)
Humidity	95% RH or less (non-condensing)
Enclosure Rating	IP20
Input Voltage	200-240V AC, 380-480V AC
