1. 4. 3a Confo rm an ce to Europ ea n E MC Directi ve
In order to conform to EMC standards, the following methods are required for line filter
application, cable shielding and drive installation. The following explains the outline of the
methods.
The line filter and the drive must be mounted on the same metal plate. The filter should
be mounted as close to the drive as practical. The cable must be kept as short as possible
and the metal plate should be securely grounded. The ground of the line filter and the
drive must be bonded to the metal plate with as much bare-metal contact as possible.
For main circuit input cables, a screened cable is recommended within the panel, and is
also suggested for external connections. The screen of the cable should be connected to
a solid ground. For the motor cables, a screened cable (max. 20 m) must be used and the
screen of the motor cable should be connected to ground at both ends by a short
connection, again using as much bare-metal contact as possible.
For more detailed explanation, refer to document EZZ006543, “Installation Guidelines For EMC
Directive using Yaskawa AC Drive Products.”
Table 1-2.1 and Figure 1-2A show the line filter list for EMC standards and the
installation/wiring of the drive and line filter.
Tab l e 1 -2. 1 . L i ne Fil t ers for Dri v e
New Drive Model Old Drive Model
Line Filter
Number Number Part Number Rated Mass Dimensions in mm
(1)
CIMR-G5M GPD 515C- 05P00325- Current (A) (kg) L x W x D
(2)
40P41F, B001,
40P71F B003
0106 8 1.8 320 x 143 x 46
41P51F, B004,
43P71F, B008, 0103 20 1.8 320 x 143 x 46
44P01F B011
45P51F, B014,
0104 30 3.0 350 x 213 x 51
47P51F B021
40111F, B027,
0105 60 5.3 435 x 268 x 56
40151F B034
40181F, B041,
0107 80 7.5 350 x 180 x 90
40221F B052
40301F B065 0108 100 13.8 420 x 200 x 130
40371F B080 0109 150 13.8 480 x 200 x 160
40451F B096 0110 160 25 480 x 200 x 160
40551F B128 0111 180 25 480 x 200 x 160
40750F, B165,
0112 300 25 480 x 200 x 160
41100F B224
41600F B302 0113 400 45 588 x 250 x 200
41850F B340 0119 500
42200F B450 0120 600
43000F B605 0121 900
1-13
(1)
1mm = 0.0394 inches
(2)
D is the distance the filter will extend outward from the surface of the metal plate.
Consult Factory
