YASKAWA GPD515C User Manual

SECTION A. 230V
TERMINAL FUNCTION
1 HP 3 TO 40 HP
L1 (R)
Three phase Main circuit input power supply
L2 (S)
200 / 208 / 220V at 50 Hz; 200 / 208 / 220 / 230V at 60 Hz
L3 (T)
T1 (U)
Three phase AC output to motor
T2 (V)
0V to max. input voltage level
T3 (W)
B1
B2
DB Resistor terminals (B1 & B2) – – – – – –
⊕ 1 DC Reactor terminals (⊕ 1 & ⊕ 2)
⊕ 2 DC Bus terminals (⊕ 1 & )
– – – – – –
⊕ 3 – – – – – – DB Unit terminals (⊕ 3 & )
l 1 (r) Power for heat sink fan:
l 2 ( s )
– – – – – –
l 1 to l 2 : 230 VAC
Ground terminal (100 ohms or less)
SECTION B. 460V
TERMINAL FUNCTION 1 TO 60 HP
L1 (R)
Three phase Main circuit input power supply
L2 (S)
380 / 400 / 415 / 460V at 50/60 Hz
L3 (T)
T1 (U)
Three phase AC output to motor
T2 (V)
0V to max. input voltage level
T3 (W)
B1
B2
DB Resistor terminals (B1 & B2) – – – – – –
⊕ 1 DC Reactor terminals (⊕ 1 & ⊕ 2)
⊕ 2 DC Bus terminals (⊕ 1 & )
– – – – – –
⊕ 3 – – – – – – DB Unit terminals (⊕ 3 & )
l 1 (r) Power for heat sink fan: Power for heat sink fan:
l 2 ( s ) l 1 to l 2 : 230 VAC l 1 to l 2 200: 230 Vac
l 2 200 ( s 200) – – – – – – l 1 to l 2 400: 460 Vac
l 2 400 ( s 400)
– – – – – –
Ground terminal
SECTION A. 230V
FUNCTION
New Model No. 20P41F -
20111F - 20151F
20181F
20300F - 20750F
TERMINAL CIMR-G5M 27P51F 20221F
Old Model No.
A003 - A033 A049 - A064
A080, -
A130 - A300
GPD515C- A096
1-6
Table 1-2. Terminal Functions and Voltages of Main Circuit
– – – – – indicates that terminals are not present.
SECTION B. 460V
FUNCTION
New Model No.
40P41F -
40151F 40181F - 40451F 40551F - 43000F
TERMINAL
CIMR-G5M
Old Model No.
B001 - B034 B041 - B096 B128 - B605
GPD515C-
