1-14
Motor Cable
max. 20m
Cable Length
max. 40cm
L2 PEL1 L3
LINE
LOAD
FILTER
GPD
515/G5
T2 PET1 T3L1 L3PE L2
Ground Bonds (remove any paint)
Ground Bonds (remove any paint)
Metal Plate
IM
3~
Figure 1-2A. Installation of Line Filter and GPD 515/G5
