1 Receiving
16 YASK AWA TOEPYAIL1E01A YASKAWA AC Drive L1000E Quick Start Guide
■ Model Number
<1> Drives with these specifications do not guarantee complete protection for the environmental conditions
indicated.
Table 1 Model Number and Specifications
Figure 4
Three-Phase 200 V Three-Phase 400 V
No.
Max. Motor Capacity
kW (HP)
3 minute 50% Duty
Rated Output
Current A
No.
Max. Motor Capacity
kW (HP)
3 minute 50% Duty
Rated Output
Current A
2A0018 3.7 (5) 17.5 4A0009 3.7 (5) 9.0
2A0022 5.5 (7.5) 21.9 4A0012 5.5 (7.5) 11.5
2A0031 7.5 (10.0) 31.3 4A0019 7.5 (10.0) 18.5
2A0041 11.0 (15.0) 41.3 4A0023 11.0 (15.0) 22.5
2A0059 15.0 (20.0) 58.8 4A0030 15.0 (20.0) 30.0
2A0075 18.5 (25.0) 75.0 4A0039 18.5 (25.0) 38.8
2A0094 22.0 (30.0) 93.8 4A0049 22.0 (30.0) 48.8
2A0106 30.0 (40.0) 106.3 4A0056 30.0 (40.0) 56.3
2A0144 37.0 (50.0) 143.8 4A0075 37.0 (50.0) 75.0
2A0181 45.0 (60.0) 181.3 4A0094 45.0 (60.0) 93.8
2A0225 55.0 (75.0) 225.0 4A0114 55.0 (75.0) 113.8
2A0269 75.0 (100.0) 268.8 4A0140 75.0 (100.0) 140.0
2A0354 90.0 (125.0) 353.8 4A0188 90.0 (125.0) 187.5
2A0432 110.0 (150.0) 432.5 4A0225 110.0 (150.0) 225.0
- - - 4A0260 132.0 (175.0) 260.0
CIMR - L E 2 A 0018 D A C
Drive
L1000
Series
No.
Enclosure Type
Design
Revision
Order
No.
Customized
Specifications
A Standard model
No.
Region
Code
IP00
D
IP00 with top
protective cover
A
South
America
No. Voltage Class
No.
Environmental
Specification
A Standard
3-phase, 380-480 Vac
3-phase, 200-240 Vac 2
4
<1>
E
YEA_common
Refer to Table 1
