B Parameter Table
170 YASK AWA TOEPYAIL1E01A YASKAWA AC Drive L1000E Quick Start Guide
C6: Carrier Frequency
No.(Addr.) Name Description Setting
C6-03
(225H)
<4> Default setting value varies by the drive model (o2-04).
Carrier Frequency
Sets the carrier frequency.
Default:
<4>
Min: 1.0 kHz
Max: 15.0 kHz
C6-06
(228H)
PWM Method
Selects PWM modulation method.
0: 2-phase/3-phase conversion
1: 2-phase modulation
2: 3-phase modulation
Default: 0
Min: 0
Max: 2
C6-09
(22BH)
Carrier Frequency during
Rotational Auto-Tuning
0: Carrier Frequency = 5 kHz
1: Setting value for C6-03
Default: 0
Min: 0
Max: 1
C6-21
(245H)
Inspection Operation Carrier
Frequency
Sets the carrier frequency during Inspection Run.
0: Setting value for C6-03
1: Carrier Frequency = 2 kHz
Default: 1
Min: 0
Max: 1
C6-23
(25EH)
Carrier Frequency during
Initial Motor Pole Search
Sets the carrier frequency when estimating the initial polarity.
0: Carrier Frequency = 2 kHz
1: Setting value for C6-03
Default: 0
Min: 0
Max: 1
C6-31
(77AH)
Carrier Frequency during
Rescue Operation
Sets the carrier frequency during Rescue Operation.
0: C6-03 setting
1: 2 kHz
Default: 0
Min: 0
Max: 1
