H1 Multi-Function Digital Input Settings
H1-
Setting
Function Description
3 Multi-Step Speed Reference 1
When input terminals are set to Multi-Step Speed References 1 through 3, switching
combinations of those terminals will create a multi-step speed sequence using the speed
references set in d1-01 through d1-08.
4 Multi-Step Speed Reference 2
5 Multi-Step Speed Reference 3
6 Jog reference selection
Closed: Jog frequency reference (d1-17) selected.
The Jog frequency can be used when the speed reference selection is not assigned to input
terminals (b1-01 ≠ 1) and the speed reference priority is set to use the multi-step speed reference
(d1-18 = 0 or 3).
7 Accel/decel Ramp Selection 1
Used to switch between accel/decel ramp 1 (set in C1-01, C1-02) and accel/decel ramp 2 (set in
C1-03, C1-04).
When combined with another input terminal set for "Accel/Decel ramp 2" (H1- = 1A), the
drive can also switch between accel/decel ramp 3 (set in C1-05, C1-06) and accel/decel ramp 4
(set in C1-07, C1-08).
8 Baseblock Command (N.O.)
Closed: No drive output
9 Baseblock Command (N.C.)
Open: No drive output
F Not Used (Through Mode)
Select this setting when the terminal is not used or when using the terminal in the pass-through
mode. The terminal does not trigger a drive function but can be used as digital input for the
controller the drive is connected to.
14 Fault Reset
Closed: Resets faults if the cause is cleared and the Up/Down command is removed.
15 Fast Stop (N.O.)
Closed: Decelerates to stop at the Fast Stop ramp set to C1-09.
16 Motor 2 Selection
Open: Motor 1(E1-, E3-)
Closed: Motor 2 (E2-, E4-)
17 Fast Stop (N.C.)
Open: Decelerates to stop at the Fast Stop ramp set to C1-09.
18 Timer Function Input
Triggers the timer set up by parameters b4-01 and b4-02. Must be set in conjunction with the
timer function output (H2- = 12).
1A Accel/decel Ramp Selection 2
Used in conjunction with an input terminal set for “Accel/decel ramp selection 1” (H1- = 7),
and allows the drive to switch between accel/decel ramp 3 and 4.
