■ LCD Display
Figure 36
Figure 36 LCD Display
Table 18 Display and Contents
<1> The STOP key has highest priority. Pressing the STOP key will always cause the drive to stop the motor, even if an Up/Down command is
active at any external Up/Down command source. To disable the STOP key priority, set parameter o2-02 to 0.
<2> The LO/RE key can only switch between LOCAL and REMOTE when the drive is stopped. By default settings the LO/RE key function is
disabled. To allow using the LO/RE key for switching between LOCAL and REMOTE, set parameter o2-01 to 1.
No. Name Display Content
1 Operation Mode Menus
MODE Displayed when in Mode Selection.
MONITR Displayed when in Monitor Mode.
VERIFY Indicates the Verify Menu.
PRMSET Displayed when in Parameter Setting Mode.
A.TUNE Displayed during Auto-Tuning.
SETUP Displayed when in Setup Mode.
2Mode Display Area
DRV Displayed when in Drive Mode.
PRG Displayed when in Programming Mode.
3 Ready Rdy Indicates the drive is ready to run.
4 Data Display – Displays specific data and operation data.
5
Speed Reference Source
Assignment
<1>
OPR Displayed when the speed reference source is assigned to the LCD Operator.
COM
Displayed when the speed reference source is assigned to MEMOBUS/Modbus
Communication.
OP Displayed when the speed reference is assigned to an option card.
6
LO/RE
Display
<2>
RSEQ Displayed when the Up/Down command is supplied from a remote source.
LSEQ Displayed when the Up/Down command is supplied from the operator keypad.
RREF Displayed when the speed reference is supplied from a remote source.
LREF Displayed when the speed reference is supplied from the operator keypad.
7
Function Key 1
(F1)
HELP
Pressing displays the Help menu.
←
Pressing scrolls the cursor to the left.
HOME
Pressing returns to the top menu (Speed Reference).
ESC
Pressing returns to the previous display.
8FWD/REV
FWD During Up command
REV During Down command
- MODE -
U1-01= 0.00%
U1-02= 0.00%
U1-03= 0.00A
DRV
Speed Ref (OPR)
Rdy
RSEQ
LREF
FWD
FWD/REV
6
5
4
123
789
