1.2 Checking Ethernet Cables
1-4
1.2 Checking Ethernet Cables
The use of incorrect Ethernet cables may impede appropriate connection with MPE720 and message
communication. For Ethernet cables, use the twisted-pair cables with RJ-45 connectors shown below.
* 1. Machine Controllers MP2300S, MP2400 and MP2310 incorporate a built-in Ethernet Module.
* 2. Some devices such as switching hubs available in the market support the automatic MDI/MDI-X function that
enables use of either straight or cross-over cables.
1.3 Checking Ethernet Communication Modes
The table below shows the communication modes of the remote device (the hub or the controller of another
manufacturer that is connected directly to the Machine Controller) in which communication is possible.
* 1. Machine Controllers MP2300S, MP2400 and MP2310 incorporate a built-in Ethernet Module.
* 2. The auto-negotiation function automatically detects the Ethernet communication mode (communication speed,
half-/full-duplex).
Module Model Ethernet Type Category Remarks
Built-in Ethernet
*1
100Base-TX Category 5 or better
• When connecting to a remote device via a hub:
Use straight cables
*2
• When connecting to a remote device directly (without
using a hub):
Use a cross-over cable
*2
218IF-02
218IF-01
10Base-T Category 3 or better
Module Model
Communication
Mode of Local
Station
Communication Mode of Remote Station
Auto-
negotiation
10Base-T
Half-duplex
10Base-T
Full-duplex
100Base-TX
Half-duplex
100Base-TX
Full-duplex
Built-in
Ethernet
*1
Auto-
negotiation
*2
Depending on
the remote
device
Communicates
only in the
10Base-T half-
duplex mode
Communi-
cation
impossible
Communicates
only in the
100Base-TX
half-duplex
mode
Communica-
tion impossible
218IF-02
218IF-01
10Base-T
half-duplex
Depending on
the remote
device
Communicates
only in the
10Base-T half-
duplex mode
Communi-
cation
impossible
Communication
impossible
Communica-
tion impossible
To Next Page
