2.4 Checking the Communication Settings
2-7
2
Troubleshooting Errors in Communication with MPE720
2.4 Checking the Communication Settings
The procedure for checking the communication settings of MPE720 version 6, and remedies, are given below.
1. Open the IP address confirmation window of the computer.
For details, refer to steps 1 and 2 in 2.3 Checking the IP Address of the Computer.
2. Start MPE720 version 6 and click Communications Setting.
The following dialog box appears.
The Communications Setting dialog box of MPE720 Version 6
3. Check that the IP address of the computer is selected in the Communication port drop-down list box
and the appropriate communication port kind is set in the Communications Setting dialog box of
MPE720 version 6.
If the communication port kind is not appropriate, select the appropriate communication port in the
drop-down list box. If the appropriate communication port or IP address is not displayed, refer to 2.5
Checking the Communication Process Settings.
IP address of the computer
Communication port kind: Ethernet
Or
Ethernet (LP)
The Communications Setting
Dialog Box of MPE720 Version 6
IP Address Confirmation Window of the Computer
To Next Page
