YASKAWA PROFINET V1000 - Forty Byte IO Produce Data

8 Communication
38 YASKAWA ELECTRIC SIEP C730600 70B V1000 Option SI-EP3/V Technical Manual
Table 20 Forty Byte IO Produce
Bytes Description
0 Status Word MSB
1 Status Word LSB
2 Output Frequency MSB
3 Output Frequency LSB
4Reserved
5Reserved
6 PG Count Value MSB
7 PG Count Value LSB
8 Motor Speed MSB
9 Motor Speed LSB
10 Frequency Reference Monitor MSB
11 Frequency Reference Monitor LSB
12 Output Current MSB
13 Output Current LSB
14 Analog Input 1 MSB
15 Analog Input 1 LSB
16 DC Bus Voltage MSB
17 DC Bus Voltage LSB
18 Fault Code MSB
19 Fault Code LSB
20 Alarm Code MSB
21 Alarm Code LSB
22 Output Power MSB
23 Output Power LSB
24 Analog Input 2 MSB
25 Analog Input 2 LSB
26 Digital Inputs MSB
27 Digital Inputs LSB
28 Analog Input 3 MSB
29 Analog Input 3 LSB
30 Configurable Input 1 MSB
31 Configurable Input 1 LSB
32 Configurable Input 2 MSB
33 Configurable Input 2 LSB
34 Configurable Input 3 MSB
35 Configurable Input 3 LSB
36 Configurable Input 4 MSB
37 Configurable Input 4 LSB
38 Configurable Input 5 MSB
39 Configurable Input 5 LSB
