 Minor Faults and Alarms
Keypad Display Fault Name
oFA03
Option fault
Option self-diagnostics error
Cause Possible Solution
The option card connection to port
CN5-A is faulty.
1. Turn off the power.
2. Check if the option is properly plugged into the option port.
3. Replace the option if the fault continues to occur.
Keypad Display Fault Name
oFA04
Option fault
Option flash write mode
Cause Possible Solution
The option card connection to port
CN5-A is faulty.
1. Turn off the power.
2. Check if the option is properly plugged into the option port.
3. Replace the option if the fault continues to occur.
Keypad Display Fault Name
to
oFA30 to oFA43
Option Card Connection Error
Communication ID error.
Cause Possible Solution
The option card connection to port
CN5-A is faulty.
1. Turn off the power.
2. Check if the option is properly plugged into the option port.
3. Replace the option if the fault continues to occur.
Keypad Display Minor Fault Name
CALL
Serial communication transmission error
Communication is not established.
Cause Possible Solution
Minor Fault
(H2- = 10)
Communication wiring is faulty.
• Check for wiring errors.
• Correct the wiring.
YES
An existing short circuit or communications
disconnection
Check disconnected cables and short circuits and repair as needed.
Programming error on the master side. Check communications at start-up and correct programming errors.
Communication circuitry is damaged.
• Perform a self-diagnostics check
• If the problem continues, replace either the control board or the
entire drive. For instructions on replacing the control board, contact
Yaskawa or your nearest sales representative.
Termination resistor of the MEMOBUS/
Modbus communications is not enabled.
Set DIP switch S2 to the ON position to enable the termination
resistor on a drive located at the end of a network line.
Keypad Display Minor Fault Name
CyPo
Cycle Power to Active Parameters
Comm. Option Parameter Not Upgraded
Cause Possible Solution
Minor Fault
(H2- = 10)
Drive is not compatible with the option
software version.
Turn off the power and upgrade the communication option
parameters.
Note: An alarm is triggered when the option software version is
earlier or an incompatible option is installed to the drive.
YES
