10 Troubleshooting
YASKAWA ELECTRIC SIEP C730600 70B V1000 Option SI-EP3/V Technical Manual 57
Option Fault Monitors U6-98 and U6-99
The option can declare error/warning conditions via drive monitor parameters on the drive digital operator as shown in
Tabl e 3 4.
Table 34 Option Fault Monitor Descriptions
Two drive monitor parameters, U6-98 and U6-99 assist in network troubleshooting:
• U6-98 displays the first declared fault since the last power cycle. U6-98 is only cleared upon drive power-up.
• U6-99 displays the present option SI-EP3/V status. U6-99 is cleared upon a network-issued fault reset and upon
power-up.
If another fault occurs while the original fault is still active, parameter U6-98 retains the original fault value and U6-99
stores the new fault status value.
Fault Condition Fault Declared
Status Value
(U6-98/U6-99)
Description
No Fault N/A 0 No faults.
Force Fault EF0 3 Network sent a message to force this node to the fault state.
Network Link Down bUS 1300 No network link to option board.
Network Failure bUS 1301 Connection with PLC Timeout.
Default MAC Address None 1303
Factory default MAC Address programmed into the option. Return for
reprogramming.
No IP Address None 1304 No IP Address has been programmed into the option.
No Station Name None 1305 No Station Name has been programmed into the option.
Config Error None 1306 Configuration error on power-up.
Init. Failure None 1307 Initialize error on power-up.
Permanent
Communication Loss
bUS 1308 Fatal error in MAC/PHY hardware, requires power cycle to recover.
