n
Optional Gasket or Sealant (Procedure 5 NEMA Type1 Enclosure)
Note: Gasket or sealant is customer supplied.
If an undesirable gap is found between Attachments 1, 2 or 3 and the drive, attach a CR-Series or EPDM-Series gasket to the
mounting panel surface or apply sealant to fill the gap. Refer to Figure 12 for sealant placement. Refer to Figure 13 for gasket
dimensions.
Gasket type: CR-Series or EPDM-Series made of foam rubber, approximately 2 mm in thick.
Sealant
Figure 12 Sealant Placement
W1
(W)
(H2)
B
H1
(H)
(H3)
(W2) (W2)
4-Md Tap
A
2-n 5 Holes
(W3)(W3)
(H3)
(H2)
Figure 13 Panel Cutout and Optional Gasket Dimensions (Procedure 5 NEMA Type1 Enclosure)
Table 8 Panel Cutout and Optional Gasket Dimensions (Procedure 5 NEMA Type1 Enclosure)
Drive Model CIMR-
Dimensions mm (in)
W H W1 (W2) (W3) H1 (H2) (H3) A B d
Vo2o0030
158
(6.2)
286
(11.3)
122
(4.8)
9
(0.4)
9
(0.4)
272
(10.7)
60
(2.4)
7
(0.3)
140
(5.5)
255
(10.0)
5
(0.2)
Vo2o0040
158
(6.2)
286
(11.3)
122
(4.8)
9
(0.4)
9
(0.4)
272
(10.7)
60
(2.4)
7
(0.3)
140
(5.5)
255
(10.0)
5
(0.2)
Vo2o0056
198
(7.8)
322
(12.7)
160
(6.3)
10
(0.4)
9
(0.4)
308
(12.1)
80
(3.1)
7
(0.3)
180
(7.0)
287
(11.2)
5
(0.2)
Vo2o0069
241
(9.5)
380
(15.0)
192
(7.5)
14
(0.5)
10.5
(0.4)
362
(14.2)
85
(3.3)
9
(0.4)
280
(8.6)
341
(13.4)
5
(0.2)
Vo4o0018
158
(6.2)
286
(11.3)
122
(4.8)
9
(0.4)
9
(0.4)
272
(10.7)
60
(2.4)
7
(0.3)
140
(5.5)
255
(10.0)
5
(0.2)
Vo4o0023
158
(6.2)
286
(11.3)
122
(4.8)
9
(0.4)
9
(0.4)
272
(10.7)
60
(2.4)
7
(0.3)
140
(5.5)
255
(10.0)
5
(0.2)
Vo4o0031
198
(7.8)
322
(12.7)
160
(6.3)
10
(0.4)
9
(0.4)
308
(12.1)
60
(2.4)
7
(0.3)
180
(7.0)
287
(11.2)
5
(0.2)
Vo4o0038
198
(7.8)
322
(12.7)
10
(0.4)
308
(12.1)
9
(0.4)
308
(12.1)
80
(3.1)
7
(0.3)
180
(7.0)
287
(11.2)
5
(0.2)
5 Installation Procedure by Drive Model
