Table A-10 Multi-function Analog Output Functions
Setting value Function (H4-01) Output signal level Remarks
0
Not used
[Not Used]
2
DC bus voltage
[DC Bus Voltage]
200 V class : 400 V/10 V
400 V class : 800 V/10 V
4
Power supply voltage
[AC Voltage]
200 V class : 200 V/5 V
400 V class : 400 V/5 V
(0 to +10 V output)
5
Current at power side
[AC Current]
Rated current /10 V
7
Power at power side
[AC Power]
Rated power /10 V
8
Power supply frequency
[AC Frequency]
60 Hz/10 V
21
Voltage deviation input
[V Deviation]
200 V class : 400 V/10 V
400 V class : 800 V/10 V
