APPENDIX CONSTANTS LIST3
65
Table A-8 Multi-function Input Functions
Setting Value
Function
(H1-01, 02)
Remarks
8
External baseblock (NO contact)
[Ext BaseBlk N.O.]
9
External baseblock (NC contact)
[Ext BaseBlk N.C.]
F
Not used
[Term Not Used]
14
Fault reset
[Fault Reset]
24
External fault
24 : NO input, Normally detected, stop
24-2F
External
fault
[External Fault]
p
y
p
Table A-9 Multi-function Output Functions
Settig value
Function
(H2-02, 03)
Remarks
0
During run
[During RUN 1]
6
Regenerative unit ready
[Regen Unit Ready]
7
During DC bus undervoltage (UV)
detection
[DC Bus Undervolt]
8
During baseblock
[BaseBlk 1]
A
During MCON
[Mc On]
E
Fault
[Fault]
F
Not used
[Not Used]
10
Alarm
[Minor Fault]
11
Fault reset command active
[Reset Cmd Active]
1E
Restart enabled
[Restart Enabled]
1F
Overload (OL1) pre-alarm
[Overload (OL1)]
80 % of the OL1
20
Overheat pre-alarm
[OH Prealarm]
