Appendix
1081
Step
Action
Description
User A is identified as the call session
initiator in the From field.
A unique numeric identifier is assigned
to the call and is inserted in the Call-ID
field.
The transaction number within a single
call leg is identified in the CSeq field.
The media capability User A is ready to
receive is specified.
The port on which User B is prepared to
receive the RTP data is specified.
F2
INVITEProxy Server to User B
The proxy server maps the SIP URI in the
To field to User B. The proxy server sends
the INVITE message to User B.
F3
180 RingingUser B to Proxy
Server
User B sends a SIP 180 Ringing response
to the proxy server. The 180 Ringing
response indicates that the user is being
alerted.
F4
180 RingingProxy Server to
User A
The proxy server forwards the 180 Ringing
response to User A. User A hears the ring-
back tone indicating that User B is being
alerted.
F5
200 OKUser B to Proxy Server
User B sends a SIP 200 OK response to the
proxy server. The 200 OK response
notifies User A that the connection has
been made.
F6
200 OKProxy Server to User A
The proxy server forwards the 200 OK
message to User A. The 200 OK response
notifies User A that the connection has
been made.
F7
ACKUser A to Proxy Server
User A sends a SIP ACK to the proxy
server, The ACK confirms that User A has
received the 200 OK response. The call
session is now active.
F8
ACKProxy Server to User B
The proxy server sends the SIP ACK to
User B. The ACK confirms that the proxy
server has received the 200 OK response.
The call session is now active.
