Configuring
Basic
Features
423
3)
(Optional.) Enter the DND off code in th
e
Of
f Code
fi
eld
.
b)
If you mark the
Custom
radio box:
1)
Select the desired account from the pull-down list of
Account
.
2)
Mark the desired radio box in the
DND Status
field.
3)
(Optional.) Enter the DND on code in the
On Code
fi
eld
.
448
450
