Product Overview

EXP40

Physical Features:

- Rich visual experience with 160 x 320 graphic LCD

- 20 physical keys each with a dual-color LED

- 20 additional keys through page switch

- Support up to 6 modules daisy-chain

- Expansion module (≤2) is powered by the host phone

- 2*RJ-12 (6P6C) ports for data in and out

- Wall Mount

EXP50
