Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/T5 Series/CP860/CP920 IP Phones

For SIP-T48G/S:

Desk Mount Method

Wall Mount Method (Optional)

Note

The top two slots on SIP-T48G/S IP phones are plugged up by silica gel. You need to pull out

silica gel before attaching the wall mount bracket.
