For line keys:
X ranges from 1 to 29 (for SIP-T48G/S)
X ranges from 1 to 27 (for SIP-T54S/T46G/T46S/T29G)
X ranges from 1 to 15 (for SIP-T42G/T42S/T41P/T41S)
X ranges from 1 to 21 (for SIP-T52S/T27P/T27G)
X ranges from 1 to 3 (for SIP-T40P/T40G/T23P/T23G)
X ranges from 1 to 2 (for SIP-T21(P) E2)
For programable keys:
X ranges from 1 to 4.
For ext keys:
For SIP-T54S/T52S:
X ranges from 1 to 3, Y ranges from 1 to 60.
For SIP-T48G/T48S/T46G/T46S:
X ranges from 1 to 6, Y ranges from 1 to 40.
For SIP-T29G/T27P/T27G:
X ranges from 1 to 6, Y ranges from 1 to 20, 22 to 40 (Ext key 21 cannot be configured).
Web User Interface:
Dsskey->Line Key/Programable Key->Label
Phone User Interface:
Menu->Features->DSS Keys->Line Key X->Label
Description:
(Optional.) Configures the short label displayed on the LCD screen for line key.
Note: It is only applicable to SIP-T52S IP phones.
Web User Interface:
Dsskey->Line Key->Short
Phone User Interface:
Menu->Features->DSS Keys->Line Key X->Short Label
To configure a directed call pickup key via web user interface:
1. Click on Dsskey->Line Key (or Programable Key).
2. In the desired DSS key field, select Direct Pickup from the pull-down list of Type.
3. Enter the directed call pickup code followed by the specific extension in the Value field.
4. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
