Yealink SIP-T2XP Administration Guide

Administrator’s Guide for SIP-T2xP IP Phones
186
Step
Action
Description
F1
INVITE—User A to Proxy
Server
User A sends a SIP INVITE message to a
proxy server. The INVITE request is an
invitation to User B to participate in a
call session.
In the INVITE request:
 The IP address of User B is inserted
in the Request-URI field.
 User A is identified as the call
session initiator in the From field.
 A unique numeric identifier is
assigned to the call and is inserted
in the Call-ID field.
 The transaction number within a
single call leg is identified in the
CSeq field.
 The media capability User A is
ready to receive is specified.
 The port on which User B is
prepared to receive the RTP data is
specified.
F2
INVITE—Proxy Server to User
B
The proxy server maps the SIP URI in the
To field to User B. The proxy server
sends the INVITE message to User B.
F3
100 Trying—User B to Proxy
Server
User B sends a SIP 100 Trying response
to the proxy server. The 100 Trying
response indicates that the INVITE
request has been received by User B.
F4
100 Trying—Proxy Server to
User A
The proxy server forwards the SIP 100
Trying to User A to indicate that the
INVITE request has been received by
User B.
F5
180 Ringing—User B to Proxy
Server
User B sends a SIP 180 Ringing response
to the proxy server. The 180 Ringing
response indicates that the User B is
being alerted.
F6
180 Ringing—Proxy Server to
User A
The proxy server forwards the 180
Ringing response to User A. User A
hears the ring-back tone indicating that
User B is being alerted.
