Yealink SIP-T40P User Manual

User Guide for the SIP-T40P IP Phone
96
1) Press or , or the Switch soft key to select Enabled from the Busy
Forward field.
2) Enter the destination number you want to forward incoming calls to when the
phone is busy in the Forward to field.
3) (Optional.) Enter the busy forward on code or off code respectively in the On
Code or Off Code field.
c) If you select No Answer Forward:
1) Press or , or the Switch soft key to select Enabled from the No
Answer Forward field.
2) Enter the destination number you want to forward unanswered incoming calls
to in the Forward to field.
3) Press or , or the Switch soft key to select the ring time to wait before
forwarding from the After Ring Time field.
The default ring time is 12 seconds.
4) (Optional.) Enter the no answer forward on code or off code respectively in the
On Code or Off Code field.
4. Press the Save soft key to accept the change or the Back soft key to cancel.
The icon on the status bar indicates that the call forward is activated.
To activate call forward in custom mode:
1. Press Menu->Features->Call Forward.
2. Press or to select the desired account, and then press the Enter soft key.

Yealink SIP-T40P Specifications

General

Wi-Fi	No
Quality of Service (QoS) support	Yes
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
Power consumption (typical)	3.23 W
Battery voltage	5 V
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	G.711, G.722, G.726, G.729A, G.729B
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	256 mm
Package width	620 mm
Package height	233 mm
Package weight	6400 g
