Yealink SIP-T58A User Manual

Basic Phone Features
283
Incoming calls will be rejected automatically and "n New Missed Call(s)" ("n" indicates the
number of missed calls. e.g., 1 New Missed Call(s)) will appear on the touch screen.
Note
To enable DND in custom mode for a specific account:
1. Swipe down from the top of the screen to enter the control center and then tap DND.
The touch screen displays a list of accounts registered on the phone.
2. Tap the desired account.
3. Tap the On radio box in the Status field.
When DND and busy forward are enabled in phone mode, all incoming calls will be forwarded to
the configured destination number. For more information on busy forward, refer to Call Forward
on page 286.

Yealink SIP-T58A Specifications

General

Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Operating system version	5.1.1
Operating system installed	Android
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Bluetooth	No
Security algorithms	SRTP
Networking standards	IEEE 802.1x
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS, IPv4/IPv6, UDP/TCP/DNS-SRV
USB 2.0 ports quantity	2
Voice codecs	G.711Mu, G.711a, G.722, G.722.1, G.722.1C, G.723, G.726, G.729ab, iLBC
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Front camera resolution (numeric)	2 MP
Base station keys	27
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
Power consumption (typical)	1.9 W
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	220 mm
Width	259.4 mm
Height	239 mm
Package depth	293 mm
Package width	324 mm
Package height	128 mm
