IM 01E24A01-01EN
Revision Information
Title : ADMAG TI Series AXW Magnetic Flowmeter [Size: 25 to 400 mm (1 to 16 in.)]
Installation Manual
Manual No. : IM 01E24A01-01EN
Edition Date Page Revised Item
1st June 2017 — New publication
2nd Sep. 2018 Front Page
1
5
6
7
28
29
36
37
41
42
47
52
56
Small revisions and add notes for explosion protected type.
Add new manual numbers and small revisions.
Add (10) to 1.1.
Add an item to IMPORTANT.
Add small revisions.
Revise Figure 3.6.3.
Add an item to CAUTION.
Add an item to CAUTION.
Add CAUTION to 4.4.3.
Add gures of explosion protected type.
Add an item to CAUTION. Add CAUTION to (4).
Revise gure of 5.2.1.
Revise Figure 5.5.
Revise Figure 6.3.1.
3rd Oct. 2018 1
2
7
9
29, 31, 35, 40
31
39
48
54
55
56, 57
59 to 61
Add new manual number for Modbus communication type.
Add trademark informations (HART, Modbus).
Revise the table for blanking plug quantity.
Add the installation location precautions.
Add the WARNING for explosion protection type.
Add the explanation of cable for Modbus communication.
Add the table for connection terminal for Modbus communication type.
Add the explanations for Modbus communication.
Add the explanation of Modbus conguration tool.
Add the information of parameter for Modbus communication.
Add the explanation of hardware switch setting for Modbus communication type.
Revise the table of error messages.
4th July 2019 Front page
1
2
3
7
31
39
49
51
52
56
67
68
69
63 to 67
Add AXG1A.
Add AXG1A.
Add Fieldbus to Trademarks.
Add EN number to (1).
Add Fieldbus to *2.
Add 4.2.4.
Add Fieldbus.
Add Fieldbus to (2), (3).
Add Fieldbus to Parameter form.
Add notes to 5.4.1, 5.4.3.
Add 5.9.2 and revise (2) HART rev.
Add a note of Fieldbus to 6.2.
Revise Figure 6.3.1.
Add Simulation Switch.
Revise Section7.
