-23-
Item Specification
Communication 1.Connection
Connect control unit cable to the external interlock connector of
CSU-X1 head
Connect control unit and PC through RS232C serial cable
Possible to connect and control two control units through daisy
chain.
1. Conditions
* Speed: 115,200 bps
* Data bit: 8
* Parity check: None
* Stop bit : 1
* Line-feed character: CR
* Separating character: colon or space
① * Case sensitivity:： Yes
Commands Shown in the command list
Power
consumption
Input：100～240VAC±10％、50 or 60Hz、200VAmax
Accessory 1. AC100VAC cable
2. Bright Field１connection cable (only for CSU-X1CU-B1)
3. Bright Field2connection cable(only for CSU-X1CU-B1)
4. CSU connection cable
5. RS232C cable （cross）
1. 6. Interlock key for control unit
6.1.2 Filter Wheel (Option)
Item Specification
Installable filters * Size: φ25mm>
* Max. 6 filters
* It is necessary to fill open position with a dummy disc for
weight balance
Exchange speed * 33msec to the adjacent position. It is necessary to wait for
33msec< before moving to the next position
* 66msec to move two positions. It is necessary to wait for
33msec< before moving to the next position
* 99msec to move three positions. It is necessary to wait for
33msec< before moving to the next position.
* Control unit makes the filter wheel move toward shortest
direction.
Accessories * 6 Aluminum disks (dummy filter) to balance weight
* Special tool to screw/unscrew filter fixing rings
* Connection cable
Power supply 24V DC 3.7A
Supplied from the control unit
