-58-
7.2 Model and Suffix Code (MS Code)
Table 7-2-1 CSU-X1 Basic Specification Codes
(*) 1800 rpm is for CSU-X1-M1 and -M2 ONLY
Table 7-2-2 CSU-X1 Suffix Code: DM (Dichroic Mirror) and BA (Barrier Filter) or fiber
Selection
Suffix Code Laser line Example of Dyes
/D*000 488nm EGFP,FITC
Dichroic
Mirror
/D*001 532nm TRITC
(DM) /D*002 568nm DsRed, mRFP
/D*100 445/488 ECFP, EGFP, FITC
/D*101 442/505/635nm ECFP, EYFP, Cy5
/D*200 405/473-491/568/635-647nm DAPI, EGFP, FITC, DsRed,
mRFP, Cy5
/D*201 445/514/635-647nm ECFP, EYFP, Cy5
/B#100 405nm DAPI
Barrier
Filter
/B#101 440-445nm ECFP
(BA) /B#102 473-491nm EGFP,FITC
/B#103 473-496nm (ArKr laser) EGFP,FITC
/B#104 505nm, 514nm EYFP
/B#105 532nm TRITC
/B#106 561nm, 568nm DsRed, mRFP
/B#107 635-647nm Cy5
Fiber /FB1 405-650nm With the standard fiber
*: means DM position: 0 for M (Manual Model), 1,2,3 for A(High-end model) to indicate
DM position. No duplicate numbers can be assigned.
#: means BA position: 0 for M (Basic model) In the case of A (High-end model), please
refer to Suffix code of CSUX1-FW (Filter wheel).
Model
Model Code
Specification
CSU-X1 ··························
Confocal scanner unit model CSU-X1
Main unit -A1····················
-A2····················
-A3····················
-M1····················
-M2····················
High-end Model
High-end Model（with BrightField）
High-end model（with Second camera）
Basic Model
Basic model（with BrightField）
Rotation
speed
H ···················
N ···················
L ···················
High Speed （10000rpm）
Standard （5000rpm）
Low Speed （1800rpm）
Language of
labels
-J ··················
-E··················
Japanese
English
