-9-
3.1.3 Option: Filter Wheel (CSUX1FW)
Necessary for CSUX1-A1,-A2,-A3 orCSUX1-M1N,-M1H,-M2N,-M2H
Part name Part number QTY Description
Filter wheel M3918MA 1 Filter wheel
Aluminum disc for
weight balance
M3916MW 6 Aluminum disc to fill open positions in the filter
wheel for weight balance
Connection cable 1
*1
M3918AP 1 Connection cable for filter wheel 1
2.5m shield cable
Connection cable 2
*1
M3918AQ 1 Connection cable for filter wheel 2
2.5m shield cable
Filter Wrench M3916CX 1 Tool for exchanging filters in the filter wheel
*1：Connection cable 1 is supplied with CSUX1FW-06P-01, and Connection cable 2 is
supplied with CSUX1FW-06P-02
CAUTION
You have to use attached cables ONLY, otherwise, it is possible to fail EMC conformity.
To Next Page
