YOKOGAWA CSU-X1 User Manual

-32-
Table 6-4-7 MOTOR2 D-Sub15 pin connector of control unit 1 CSUX1CU-F1)
Pin No. Function I/O Connection
1 MOTOR2 output Output
2 MOTOR2 output Output
3 MOTOR2 output Output
4 MOTOR2 output Output
5 MOTOR2 output Output
6 MOTOR2 output Output
7 MOTOR2 output Output
8 MOTOR2 output Output
9 Unconnected
10 Unconnected
11 Sensor input Input
12 Unconnected
13 Unconnected
14 Source for sensor (24V)
15 GND for sensor
Table 6-4-8 MOTOR1 D-Sub15 pin connector of control unit 2 (CSUX1CU-B1)
Pin No. Function I/O Connection
1 Unconnected
2 Unconnected
3 Unconnected
4 Unconnected
5 Unconnected
6 Unconnected
7 Unconnected
8 MOTOR1output Output
9 MOTOR1output Output
10 MOTOR1output Output
11 Sensor input Input
12 MOTOR1output Output
13 MOTOR1output Output
14 Source for sensor
15 GND for sensor
