-51-
Item Specification
2. Life: on/off total count 60,000<
3. Continuous open/shut frequency: 3Hz>
Emission range
420～700nm
BA (barrier) filter 1. Standard: None
2. Option: BA line-up is shown in the Table 7-2-2
(CAUTION) You must install optimal BA filter to match
the laser and DM.
BA filter position and
exchange
1. Basic model
One position in the filter slot at each of 1
st
and 2
nd
camera port. Filter size:φ25mm
2. High-end Model
* To use Filter Wheels installed in the filter slot at each
of 1
st
and 2
nd
camera port
* CSU-X1FW-06P-01: Filter Wheel for 1
st
camera port
* CSU-X1FW-06P-02: Filter Wheel for 2
nd
camera port
* CSU-X1CU-F1 control unit is required to use
CSU-X1FW-06P-01.
Bright Field
(Non-confocal)/Confocal
switching
1 Light path exchange (High-end mode)：
* Motor driven: Requires CSU-X1CU-B1(Bright Field
control unit)
2 Light path exchange (Basic mode)
* Manually exchange two ports with each lever
Microscope connection 1. Standard: C mount of each microscope
2. Option for Bright Field:
Microscope specific connectors are necessary to install
Bright Field unit. Specific connectors for Olympus,
Nikon, Zeiss, Leica , upright/inverted microscopes are
available as option.
Switching between 1
st
and
2
nd
camera port
1 .Light path exchange (High-end model)：
Motor driven: Requires CSU-X1CU-B1(Bright Field
control unit)
2 Light path exchange (Basic model)
Manual exchange with a port exchange lever
Camera port
1.Standard：
* 1
st
camera port: C mount （X 1）
* 2
nd
camera port position: covered
2.Option：
* 2
nd
camera port with C mount (X 1)
* C mount adapter for EMCCD (X 1.2 for 8×8mmCCD
chip） available for both 1
st
/2
nd
camera port
* Eye piece for direct view of confocal image at 2
nd
port.
(WARNING) To install the direct view eye piece,
appropriate barrier filter to cut the excitation laser has
to be installed for laser safety.
