-15-
3.3.2.2 CSUX1CU-B1 Model
Following connection is necessary to use Bright Field with CSUX1-A2 and A3
models.
(1) Connect RS232C2 connector of control unit 1 (CSUX1CU-F1) and RS232C1
connector of control unit 2 (CSUX1CU-B1) with supplied cable.
(2) Connect controller interlock key to EXT INTERFACE1/I.LOCK.
(3) Connect MOTOR1 of control unit 2 (CSUX1CU-B1) and BF1 connector of CSU-X1
with supplied Bright Field cable (BF1).
(4) Connect NOTOR2 and BF2 connector with supplied Bright Field 2(BF2) cable.
(Not necessary for A3 model.)
(5) After checking the power switch is OFF, connect the power cable
Please use the power receptacle which fulfills the following conditions.
* 3 pole electric socket equipped with protective earth terminal.
* Rated supply voltage：100～240VAC
* Power voltage frequency range：90～264VAC
* Rated supply frequency：50～60Hz
* Power frequency latitude：48～63Hz
* Maximum electric power consumption：200VA
Please follow the warnings and cautions below before connecting the power supply of
control unit. If these warning and cautions were not followed, there is a possibility of
causing an electric shock or breakage of apparatus.
WARNING
• Please confirm your power supply is suitable for the rated supply voltage of
this unit before connection.
• Please confirm before connecting the power cord if the power switch of this
unit is off.
• Please ONLY use supplied power code to prevent electrical shock or fire.
• Please be sure to ground the protective earth for electric shock prevention.
• Please always use 3-prong plug with protective earth terminal to avoid risk
of electrification.
• Please do not use the extension code without a protective earth conductor.
Use of such will cancel out protection.
To Next Page
