C-Bus Analysis Function
?
TYPE <Space>
I2CBus
?
TYPE <Space> PA TTern
INDefinite
?
?
1.7 Communication Commands
:SEARch:I2C:ANALyze:SETup?
Function Queries all settings related to the I
2
C analysis
condition.
Syntax :SEARch:I2C:ANALyze:SETup?
Example :SEARCH:I2C:ANALYZE:SETUP? ->
:SEARCH:I2C:ANALYZE:SETUP:CLOCK:
SOURCE 1;LEVEL 1.000E+00;
HYSTERESIS 0.3;:SEARCH:I2C:ANALYZE:
SETUP:DATA:SOURCE 2;
LEVEL 1.000E+00,0.000E+00;:SEARCH:
I2C:ANALYZE:SETUP::RPOINT TRIGGER;
MPOSITION -4.00000
:SEARch:I2C:ANALyze:SETup:CLOCk?
Function Queries all settings related to the clock channel of
the I
2
C analysis condition.
Syntax :SEARch:I2C:ANALyze:SETup:CLOCk?
Example :SEARCH:I2C:ANALYZE:SETUP:CLOCK? ->
:SEARCH:I2C:ANALYZE:SETUP:CLOCK:
SOURCE 1;LEVEL 1.000E+00;
HYSTERESIS 0.3
:SEARch:I2C:ANALyze:SETup:CLOCk:
HYSTeresis
Function Sets the clock channel hysteresis of the I
2
C
analysis condition or queries the current setting.
Syntax :SEARch:I2C:ANALyze:SETup:CLOCk:
HYSTeresis {<NRf>}
:SEARch:I2C:ANALyze:SETup:CLOCk:
HYSTeresis?
<NRf>=0.3 to 4.0 (divisions, 0.1
steps)
Example :SEARCH:I2C:ANALYZE:SETUP:CLOCK:
HYSTERESIS 0.5
:SEARCH:I2C:ANALYZE:SETUP:CLOCK:
HYSTERESIS? -> :SEARCH:I2C:ANALYZE:
SETUP:CLOCK:HYSTERESIS 0.5
:SEARch:I2C?
Function Queries all settings related to the I
2
C analysis
function.
Syntax :SEARch:I2C?
Example :SEARCH:I2C? -> :SEARCH:I2C:ANALYZE:
SETUP:CLOCK:SOURCE 1;
LEVEL 1.000E+00;HYSTERESIS 0.3;:
SEARCH:I2C:ANALYZE:SETUP:DATA:
SOURCE 2;LEVEL 1.000E+00,0.000E+00;:
SEARCH:I2C:ANALYZE:SETUP::
RPOINT TRIGGER;MPOSITION -4.00000;:
SEARCH:I2C:SEARCH:TYPE PATTERN;
ADDRESS:MODE 1;PATTERN “X0X10X10”;
ACK “X”;:SEARCH:I2C:SEARCH:DATA:
MODE 1;PATTERN “10X10X10”;ACK “X”
:SEARch:I2C:ANALyze?
Function Queries all settings related to the I
2
C analysis
execution.
Syntax :SEARch:I2C:ANALyze?
Example :SEARCH:I2C:ANALYZE? -> :SEARCH:I2C:
ANALYZE:SETUP:CLOCK:SOURCE 1;
LEVEL 1.000E+00;HYSTERESIS 0.3;:
SEARCH:I2C:ANALYZE:SETUP:DATA:
SOURCE 2;LEVEL 1.000E+00,0.000E+00;:
SEARCH:I2C:ANALYZE:SETUP::
RPOINT TRIGGER;MPOSITION -4.00000
:SEARch:I2C:ANALyze:ABORt
Function Aborts the I
2
C analysis execution.
Syntax :SEARch:I2C:ANALyze:ABORt
Example :SEARCH:I2C:ANALYZE:ABORT
:SEARch:I2C:ANALyze:EXECute
Function Executes the I
2
C analysis.
Syntax :SEARch:I2C:ANALyze:EXECute
Example :SEARCH:I2C:ANALYZE:EXECUTE
