YOKOGAWA DL1640 User Manual

1-28
IM 701610-61E
1.7 Communication Commands
Command Function Page
I
2
C Trigger Group
:TRIGger:I2C? Queries all settings related to the I
2
C trigger. 1-31
:TRIGger:I2C:ADDRess?
Queries all settings when the I
2
C trigger type is set to Address&Data. 1-31
:TRIGger:I2C:ADDRess:ADDRess? Queries all settings related to the Address pattern when the I
2
C trigger
type is set to Address&Data. 1-31
:TRIGger:I2C:ADDRess:ADDRess:HEXa Sets the Address pattern in hexadecimals when the I
2
C trigger type is
set to Address&Data. 1-31
:TRIGger:I2C:ADDRess:ADDRess:MODE Sets the valid/invalid setting of the Address pattern when the I
2
C trigger
type is set to Address&Data or queries the current setting. 1-31
:TRIGger:I2C:ADDRess:ADDRess:PATTern
Sets the Address pattern in binary when the I
2
C trigger type is set to
Address&Data or queries the current setting. 1-31
:TRIGger:I2C:ADDRess:DATA? Queries all settings related to the Data pattern when the I
2
C trigger type
is set to Address&Data. 1-31
:TRIGger:I2C:ADDRess:DATA:CONDition Sets the trigger condition of the Data pattern when the I
2
C trigger type is
set to Address&Data or queries the current setting. 1-32
:TRIGger:I2C:ADDRess:DATA:HEXa Sets the Data pattern in hexadecimals when the I
2
C trigger type is set to
Address&Data. 1-32
:TRIGger:I2C:ADDRess:DATA:MODE Sets the valid/invalid setting of the Data pattern when the I
2
C trigger type
is set to Address&Data or queries the current setting. 1-32
:TRIGger:I2C:ADDRess:DATA:PATTern Sets the Data pattern in binary when the I
2
C trigger type is set to
Address&Data or queries the current setting. 1-32
:TRIGger:I2C:ADDRess:DATA:POSItion Sets the comparison position of the Data Pattern when the I
2
C trigger
type is set to Address&Data. 1-32
:TRIGger:I2C:ADDRess:IREStart I
2
C Sets whether to ignore the restart condition (YES/NO) of the Address
trigger condition or queries the current setting. 1-32
:TRIGger:I2C:ADDRess:IUNexpected I
2
C Sets whether to ignore the start/stop conditions (YES/NO) that do not
conform to the protocol of the Address trigger condition or queries the
current setting. 1-32
:TRIGger:I2C:COMBination Sets the I
2
C trigger combination or queries the current setting. 1-32
:TRIGger:I2C:PATTern? Queries all settings related to the I
2
C trigger pattern setting. 1-32
:TRIGger:I2C:PATTern:CHANnel<x> Sets the channel condition of the I
2
C trigger pattern condition or queries
the current setting. 1-33
:TRIGger:I2C:PATTern:CONDition Sets the trigger condition of the I
2
C trigger pattern condition or queries
the current setting. 1-33
:TRIGger:I2C:TYPE Sets the I
2
C trigger type or queries the current setting. 1-33
:TRIGger:TYPE Sets the trigger type or queries the current setting. 1-33
I
2
C Analyze Group
:SEARch:I2C? Queries all settings related to the I
2
C analysis function. 1-35
:SEARch:I2C:ANALyze? Queries all settings related to the I
2
C analysis execution. 1-35
:SEARch:I2C:ANALyze:ABORt Aborts the I
2
C analysis execution. 1-35
:SEARch:I2C:ANALyze:EXECute Executes the I
2
C analysis. 1-35
:SEARch:I2C:ANALyze:SETup? Queries all settings related to the I
2
C analysis condition. 1-35
:SEARch:I2C:ANALyze:SETup:CLOCk? Queries all settings related to the clock channel of the I
2
C analysis
condition. 1-35
