2-27
IM 701610-61E
SPI Bus Signal Analysis Function
2
2.7 Error Messages
This section lists only the error messages related to the SPI bus signal analysis function.
There are other error messages related to the DL1640/DL1640L and communications.
These messages are described in the
DL1620/DL1640/DL1640L User’s Manual IM
701610-01E
and the
Communication Interface User’s Manual IM 701610-17E
.
Warnings
Code Message
37 Analysis aborted.
38 Data not detected. Execute again after changing the settings or reacquiring the waveform.
Errors
Code Message
779 Specified data does not exist. Execute the analysis.
950 Cannot be specified. Invalid byte or bit.
951 Cannot be set when CS channels are not specified.
To Next Page
