YOKOGAWA DL1640 User Manual

3-1
IM 701610-61E
Specifications
3
Chapter 3 Specifications
3.1 I
2
C-Bus Signal Analysis Function
Applicable Bus
I
2
C-Bus
Bus transfer rate: Up to 3.4 Mbits/s
Address mode: 7 bits
SM Bus
Conforms to the System Management Bus
Trigger Function
Trigger Source
CH1: SCL
CH2: SDA
CH3, CH4: Analog signal input
Start Trigger
Activates a trigger on a Start condition.
Non-ACK Trigger
Activates a trigger when an acknowledge is not present.
Address Trigger
Compares with the specified address.
Data Trigger
Compares with the specified data.
Combination Trigger
Set the trigger condition by combining the analog signals of CH3/CH4 and the SCL/SDA
signals.
Analysis Function
Detailed Data Display Mode
The time from the Reference Position, the data (simultaneously displays binary and
hexadecimal values), and the presence of an acknowledge
Waveform and Data Display Mode
Simultaneously displays the data (hexadecimal) and the waveform
Number of Data Points That Can Be Analyzed
Up to 40000 bytes (20000 bytes before and after the reference point)
Search Function
Pattern Search
Searches data that matches the specified address pattern, data pattern, or Acknowledge
bit condition.
Indefinite Data Search
Searches indefinite data.
